Industries

Dimartech is the trusted partner for engineering and fabrication of custom industrial process equipment by leading OEMs and clients across a vast variety of industries.

Mining

Due to the rugged nature of the mining and aggregates industries, reliable and robust equipment is needed to handle abrasive, corrosive and compacting environments.

Rotary kilns and dryers, rotary calciners, rotary cooler disk mixers, slurry mixers, and air separators.

Rotary Dryer Shell, 10’-0’’ (3 m) dia. x 70’-0’’ (21 m) long, SS316L, 70,000 lbs (32000 kg), internal lifter plates and baffles (Alberta)

Rotary Calciner, Hastelloy 800HT shell, SS316L breechings, overall 45ft (13.7 m) long (Labrador)

Truck bodies for off-highway trucks for Internationally renowned truck companies (North America)

Rotary Calciner (Discharge End), Hastelloy 800HT shell, SS316L breechings, overall 45ft (13.7 m) long (Labrador)

Rotary Calciner (Detail of turning roll assembly), Hastelloy 800HT shell, SS316L breechings, overall 45ft (13.7 m) long (Labrador)

Rotary Disc Cooler, SS316L rotary discs and trough body, ASME Sect.VIII Div.1 design (Nevada, USA)

Environmental

Environment Compliance Management

Fuel Storage Tank Install, Modification & Withdrawal (SOR/2008-197)
Halocarbon containing equipment (SOR/2003-289)
Hazardous Materials Storage & Disposal (SOR/88-66 & SOR/2001-286)
Hazardous Waste Storage & Disposal (R.R.O. 1990 Reg. 347 & SOR/2001-286)
PCB containing equipment (SOR/2008-273)

Environmental Site Assessment (O. Reg. 153/04) – Phase I, Phase II, Phase III

Waste Audits and Waste Reduction Work Plans (O.Reg 102/94)

Reactor per ASME Sect.VIII Div.1, SA-516.70 3’’ (75mm) plate, 1200 psi MAWP, 8ft dia. x 50ft long, internal cladding in SS316L, internal tube bundle SS316L, 14’’ thick custom made weld neck flanges, all bolting 3.75’’ dia., total 260,000 lbs, (Alberta)

Reactor (Main shell assembly) per ASME Sect.VIII Div.1, SA-516.70, total 150,000 lbs (68000 kg) (Alberta)

Reactor (internal tube bundle) per ASME B31.3, sch.160 piping SS316L (Alberta)

Biomass gasifier for treatment of domestic solid waste, SS316L and refractory lined carbon steel (U.S. Navy base)

Energy

Dimartech’s exceptional design-engineering and project management team has the ability to meet the technically demanding equipment required for today’s evolving energy industry, including petrochemical, renewables or gas turbine energy sectors.

Spherical pressure vessels per ASME Sect.VIII Div.1, SA-516.70 1.25” (32mm) plate, two (2) 35ft (10.7m) dia., one (1) 45ft (13.7m) dia. shop fabrication and pre-assembly at Dimartech facility

Pressure Vessels — Three (3) spherical pressure vessels: completed field assembly (Montreal)

Disintegrator (Ethanol production) per ASME Sect.VIII Div.1, SS316L (Wisconsin, USA)

Disintegrator beater blade assembly (Ethanol production) per ASME Sect.VIII Div.1, SS316L(Wisconsin, USA)

Horizontal camelback for hydro turbines (Ontario).

Pressure vessel, per ASME Sect.VIII Div.1, SS316L (Nunavut)

Pressure vessel per ASME Sect.VIII Div.1, SA-516.70 (Quebec)

Aerospace

The aerospace industry is a constantly evolving and demanding sector, where high performance is required and where there is no room for error.

Dimartech is a solid partner when you need components for use in aircraft engine testing. With our high level of expertise in welding and dimensional accuracy, we deliver high-tolerance parts for the aerospace industry.

Each of our precision-machined and fabricated components is backed by our ironclad reputation.

Collector Diffusers, SS321, 4.5m x 4.5m x 2.2 m, eight (8) built for various GTE test facilities in North America and Europe

Exhaust Collector Diffuser, SS321, 4.5m x 4.5m x 2.2 m, eight (8) built for various GTE test facilities in North America and Europe

Exhaust Collector Diffuser (packaged for international Ocean Shipping)

Institutional

Hydrology research facilities within university graduate student laboratories required a complete turnkey solution for a custom built Shallow Flume (design, manufacturing, installation, commissioning and training for users).

40 feet long water containment flume with 1-ply tempered glass supported on a custom-built support structure with 2-way mechanical tilting. Piping, instrumentation and electrical work complete the scope of supply.

Internal baffles diverge the water flow and specifically adapted cameras record the water flow movement and record varying degrees of laminar and turbulent flows for graduate student research.
